| Model | GAZ-3409 "Bobr" | |
| Seating | 6 | |
| Curb weight, kg | TOTAL | 2,900 |
| front axle | - | |
| rear axle | - | |
| Gross weight, kg | TOTAL | - |
| front axle | - | |
| rear axle | - | |
| Payload [carrying capacity] weight, kg | 225 (or 600 if 2 people) | |
| Permissible [semi-]trailer weight, kg | - | |
| Length, mm | 4350 | |
| Width, mm | 2000 | |
| Height, mm | 2460 | |
| Wheelbase, mm | 2400 | |
| Track width, mm | caterpillar | 1500 |
| - | - | |
| Minimal ground clearance, mm | under front axle | 400 |
| under rear axle | 400 | |
| Minimal radius of turn, m | b/n curbs (outer front wheel) | - |
| b/n walls (extreme exterior dimension | - | |
| Maximum speed, km/h | 65 (on water 5) | |
| Fuel reserve on land, km | 600 | |
| Acceleration time from 0-60 km/h, seconds | 22 | |
| Transmission | gearbox | 5 x 2 speeds |
| gearbox ratios | - | |
| main gear ratio | - | |
| transfer case ratio | - | |
| clutch | - | |
| Wheels | number | - |
| tire size | - | |
| tire pressure, kg/cm2 | - | |
| Suspension | front | - |
| rear | - | |
| Steering | gear | control arm |
| gear ratio | - | |
| Brakes | braking distance, m | - |
| service (foot) | drum | |
| parking (hand) | - | |
| Filling capacities, liters | fuel tank | 70 |
| engine cooling system | - | |
| engine lubrication system | - | |
| gearbox housing | - | |
| axle housing | - | |
| steering system cylinder | - | |
| shock absorbers | - | |
| hydraulic brake drive | - | |
| air filter | - | |
| Carburetor | - | |
| Electric equipment | - | |
| Accumulator battery | - | |
| Generator [alternator] | - | |
| Relay-regulator | - | |
| Starter motor | - | |
| Timer-distributor | - | |
| Spark plugs | - | |
| Engine | engine type | GAZ-5601, diesel, 4 cyl., 8 valve, in-line, ohv |
| cylinder work order | - | |
| maximum horsepower, hp | 110 @ 3800 rpm | |
| maximum torque, N·m | 255 @ 2000 rpm | |
| displacement, liters | 2.130 | |
| compression ratio | - | |
| bore/stroke, mm | - | |
| Years of production | 1999 | |
| Overall units made | several | |
| Wheel arrangement | caterpillar | |
| Pictures | 42 KB (b/w, side view, sketch [11]) | |
This off-road vehicle has ground pressure of only 0.14 kgs/cm2 which allows it to travel on sand and snow.
Translation of "Bobr" in English is "Beaver"
